Color

Overview

FOVNO's pioneering work appeared like a phantom at the end of 2017, breaking the predicament that China has not had a full CNC process crank for many years. The whole body of the crank arm is CNC-finished, the axis is made of 7075 top aluminum alloy, and the inner hollowing and turning-milling composite technology makes the overall weight and strength have good performance. Since its launch in late 2017, it has conquered many mountain bike enthusiasts at home and abroad with its colorful and cool appearance, outstanding performance and super cost-effective. This crank has two versions of the conventional 68/73 bottom bracket and 83 bottom bracket (DH), which also provides a good choice for riders who like downhill.

Model

MC-018

RRP

¥449~479(Crank)

Specifications

Material

Crank 6061 Al Alloy、Spindle 7075 Al Alloy

Technics

Full CNC

Spindle

24mm

Q-factor

168mm/183mm(DH Type)

Length

170mm/175mm

Weight

551g(170mm Crank)

BB Compatibility

68/73mm BSA、89.5/92mm Press-Fit
83mm BSA(DH Type)、104.5/107mm Press-Fit(DH Type)

Rider Style

XC/Trail/AM/DH

Combination Method

Chian line:48mm

Weight:647g

Split Type

Chian line:49mm

Weight:625g

Direct Type

Crank
